SSLMFM10LDD
Product Parameters
| Nominal shaft diameter | 10 |
|---|---|
| Extended middle circular flange | SSLMFM10LDD |
| Weight (g) | 86.2 |
| Lengthened middle method flange | SSLMKM10LDD |
| Weight (g) | 69.4 |
| dr(mm) | 10 |
| tolerance | 0/-10 |
| D(mm) | 19 |
| tolerance | 0/-16 |
| L(mm) | 55 |
| tolerance | ±300 |
| I (mm) | 24.5 |
| Df(mm) | 40 |
| K mm | 30 |
| t(mm) | 6 |
| Dp (mm) | 29 |
| X(mm) | 4.5 |
| Y (mm) | 7.5 |
| Z (mm) | 4.1 |
| eccentric | 15 |
| verticality | 15 |
| Dynamic load CN | 588 |
| Static load Co N | 1100 |
